GSM dry process ball mill
GSM stirred type grinding machine has the unique patented design concept. It contains a brand new internal structure of the grinding cylinder, where allows for a higher degree of rotation speed to realize finer grinding, which adopts continuous operation of side way discharge.
GSM has a series of special shape of mixing arm, the bypass plate is axial mounted on the stirring shaft, this brand new design can use smaller grinding medium and higher RPM speed to increase the time duration of the material in the grinding chamber, thus could guarantee the material to have more fine granularity.
Accessories and options△ fully integrated system△ stainless steel grinding cylinder△ all-jacket grinding cylinder△ air cooling or explosion-proof motor△ high efficiency bottom discharging.
Technical parameters
| Model |
GSM-40 |
GSM-100 |
GSM-300 |
| Grinding cylinder volume(L) |
39 |
108 |
322 |
| Amount of grinding medium(L) |
19 |
45 |
144 |
| Power(kw) |
5.5 |
7.5 |
11 |
| Height H(m) |
1.5 |
1.89 |
2.61 |
| Floor area |
1.35x0.8 |
1.7x0.9 |
2.1x1.22 |
| Weight(t) |
0.8 |
1.84 |
3.5 |
